APPLICATIONS: Designed for use with Commercial and industrial fans, blowers, pumps, and other machinery that have variable torque characteristics. Prolonged use at low speed can result in significant energy savings. Dripproof motors are intended for use in environments that are relatively clean and dry. For use outdoors an enclosure or drip cover may be required.
FEATURES:
- Two-Speed, Two-Winding
- Class F Insulation
- Dynamically balanced rotors
- Dual frame mounting
- Ball Bearings
- UL Recognized and CSA Certified
This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.
Specifications
|
Brand: |
Marathon |
|
Application: |
Two Speed |
|
Output HP: |
2/0.90 |
|
Output KW: |
1.5/0.67 |
|
Output RPM: |
1775/1182 |
|
Frame Size NEMA: |
182T |
|
Mount NEMA: |
With Base |
|
Enclosure NEMA: |
DP |
|
Enclosure IEC: |
IP22 |
|
Voltage: |
200-230 |
