APPLICATIONS: Used in a diverse range of applications from food and drink to water and sewage, from heating and ventilation to refrigeration. Some of the benefits of aluminum over cast iron include high resistance to corrosion and atmospheric attack (except chlorine, salt-laden or sulphuric acid) and the fact that aluminum is approximately one third the weight of cast iron.
- Removable base
- NEMA MG1-PART 31 Inverter Duty
- VPI Impregnation Tropicalized
- Class F insulation
- Split conduit box is 90 degrees rotatable
- Warranty: 3 Years
- CSA approved for Class I ; Division 2
Specifications
|
Brand: |
Brook Crompton |
|
Application: |
General Purpose |
|
Output HP: |
10 |
|
Output KW: |
7.5 |
|
Output RPM: |
3600//3000 |
|
Frame Size IEC: |
132SD |
|
Mount IEC: |
B35 Foot/Flange |
|
Enclosure NEMA: |
TEFC |
|
Enclosure IEC: |
IP55 |
|
IEC Shaft Dia.: |
38mm |
