APPLICATIONS: For use on pumps designed for fire pump duty and installed per NFPA-20. These drip proof motors are intended for installation in relatively clean and dry environments. Fire Pump motors are not recommended for use with variable frequency drives.
FEATURES:
- UL File EX5190, CSA File LR2025 and CE Mark
- 1.15 Service Factor
- Red paint on 25 HP through 200 HP
- NEMA Design B, Code G or less
- Dual voltage motors have 12 leads, suitable for wye-delta or across the line start on either voltage, or part winding start on low voltage
Specifications
|
Brand: |
Marathon |
|
Application: |
Fire Pump |
|
Output HP: |
100 |
|
Output KW: |
75 |
|
Output RPM: |
1783 |
|
Frame Size NEMA: |
404TS |
|
Mount NEMA: |
With Base |
|
Enclosure NEMA: |
DP |
|
Enclosure IEC: |
IP23 |
|
Voltage: |
230/460 |
