APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.
SPLIT-PHASE: A single-phase motor that consists of a running winding, starting winding, and centrifugal switch. The reactance difference in the windings creates separate phases, which produce the rotating magnetic field that starts the rotor.
FEATURES:
- Economical split phase design or capacitor start designs
- Heavy gauge steel frame and base
- UL Recognized and CSA Certified
Specifications
|
Application: |
General Purpose |
|
Output HP: |
1/6 |
|
Output KW: |
0.12 |
|
Output RPM: |
1725 |
|
Frame NEMA: |
48 |
|
Mount NEMA: |
Base Mount |
|
Enclosure NEMA: |
DP |
|
Voltage: |
115 |
|
Frequency (Hz): |
60 |
|
Efficiency: |
48.5 |
