LEESON Three Phase JP Pump Motors are designed for continuous duty service on close-coupled pumps using NEMA JP mounting and shaft dimensions. In such applications, the pump impeller is mounted directly on the motor shaft. Designed for continuous duty service. All motors listed are 1.15 Service Factor.
Features:
- Locked bearing on shaft end limits axial shaft movement
- For use where the environment is relatively clean and dry
- For outdoor use, an enclosure or drip cover may be preferred
- Drip cover not included. Use drip cover part number 175932.00
- High efficiency copper windings with NEMA 1.15 service factors
- UL and CSA recognized designs
- All 180 and 210 frame rolled steel motors have Class F Insulation
Specifications
|
Brand: |
Leeson |
|
Application: |
Closed Coupled |
|
Output HP: |
1.5 |
|
Output KW: |
1.1 |
|
Output RPM: |
3515 |
|
Frame Size NEMA: |
143JP |
|
Mount NEMA: |
C Face With Base |
|
Enclosure NEMA: |
DP |
|
Enclosure IEC: |
IP22 |
|
Voltage: |
230/460//190/380 |
