APPLICATIONS: Designed for direct replacement of PMDC or any other variable speed application where up to a 1000:1 constant torque speed range is required. Typical uses include: machine tools, conveyors, packaging machines, batching machines, and printing equipment.
FEATURES:
- Designed to replace PMDC motors (when used with a VFD)
- Constant horsepower to twice base speed (RPM)
- Class H insulation with CR200 magnet wire
- Continuous duty at 40ºC ambient
- “Quick Connect” terminal board
- Top mounted conduit box as found on PMDC motors
- Eliminates brush and commutator maintenance
- UL Recognized, CSA Certified, and CE Mark
- Three year warranty
Specifications
|
Brand: |
Marathon |
|
Application: |
Vector Duty |
|
Output HP: |
1/4 |
|
Output KW: |
0.19 |
|
Output RPM: |
1725 |
|
Frame Size NEMA: |
56C |
|
Mount NEMA: |
C Face No Base |
|
Enclosure NEMA: |
TENV |
|
Enclosure IEC: |
IP43 |
|
Voltage: |
230 |
