APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.
SPLIT-PHASE: A single-phase motor that consists of a running winding, starting winding, and centrifugal switch. The reactance difference in the windings creates separate phases, which produce the rotating magnetic field that starts the rotor.
FEATURES:
- No overload protection
- Split Phase design
- Ball bearing
- Shaft extension 1-1/2” long by 1/2” diameter
- 1.0 Service Factor
- Heavy gauge steel frame and base
- UL Recognized and CSA Certified
- Footnotes: 3,7,17
Specifications
|
Application: |
General Purpose |
|
Output HP: |
1/3 |
|
Output KW: |
0.25 |
|
Output RPM: |
1725 |
|
Frame NEMA: |
48 |
|
Mount NEMA: |
Resilient Base |
|
Enclosure NEMA: |
DP |
|
Voltage: |
115 |
|
Frequency (Hz): |
60 |
|
Efficiency: |
59.5 |
