APPLICATIONS: Designed specifically for severe “farm duty” environments and applications, but work very well in standard environments such as Air compressors, pumps and other single phase machinery.
Mechanical Features:
- Made in USA
- Steel frame
- 5/8″ shaft output diameter
- Pressure washer duty
- Gasketed capacitor housing and conduit boxes provide protection in all environments.
- Double sealed ball bearings pre-lubricated with Exxon POLYREX EM grease having operating temperature range of -20*F to +350*F and special formulation to provide extra bearing protection.
- Rubber boot over manual protector reset button provides weather protection.
Electrical Features:
- Low temperature manual overload protector protects against extreme overload.
- Class “F” copper windings and varnish.
- Capacitor start provides high starting torque with normal starting current.
Specifications
|
Application: |
Farm Duty |
|
Output HP: |
1/2 |
|
Output KW: |
0.37 |
|
Output RPM: |
1725 |
|
Frame NEMA: |
56C |
|
Mount NEMA: |
C-Face With Base |
|
Enclosure NEMA: |
TEFC |
|
Enclosure IEC: |
IP43 |
|
Voltage: |
115/208-230 |
|
Frequency (Hz): |
60 |
