APPLICATIONS: includes food processing conveyors and feeders where the motor is exposed to high pressure wash down.
- Moisture sealant on blot heads between frame and endplates
- 5/8″ Keyed output shaft
- Neoprene gasketed conduit box
- Double sealed ball bearings
- Forsheda® running contact v-ring slinger
- Stainless steel shaft
- Electrostatic epoxy paint coating
- Class F insulation
- Tach adaptable
- 3300P motors are TENV, all others are TEFC
Specifications
|
Application: |
Epoxy Washdown |
|
Output HP: |
1/2 |
|
Output KW: |
0.37 |
|
Output RPM: |
1750 |
|
Frame NEMA: |
56C |
|
Mount NEMA: |
C-Face With Base |
|
Input Voltage DC: |
180 |
|
Full Load Amps: |
2.5 |
|
Winding: |
Permanent Magnet |
|
Enclosure NEMA: |
TENV |
